CL-2H compression terminals, UL486. Tin-plated copper, closed barrel, 600V 90°C. Color-coded. For high-vibration industrial circuits.
Application
CL-2H compression terminals (600V) per UL 486, for high-vibration commercial and industrial power/control circuits. Rated 90°C, tin-plated copper, color-coded for wire size, closed barrel prevents strand damage, heat-shrink insulator available. Fits electrical panels, motors, and distribution blocks.
Core Strengths
Loose terminals loosen under vibration. Our UL 486 CL-2H closed-barrel terminals have tin-plated copper, rated 600V, 90°C, color-coded.
Standard
Construction
☉〉 Material: High-conductivity copper tube (>99.9% pure)-7
☉〉 Plating: Electro-tin plated for corrosion resistance-1
☉〉 Barrel Type: Long barrel design for multiple crimps and enhanced mechanical pull-out strength-11
☉〉 Pad: Double-hole pad for secure two-point fixing
Features
☉〉 Voltage rating: Suitable for up to 35kV applications-11
☉〉 Wide conductor range: For copper conductors from 14 mm² up to 500 mm²-10
☉〉 Working temperature: -55°C to +150°C, ideal for harsh environments-10
☉〉 Inspection hole: Allows visual verification of full conductor insertion-11
☉〉 Safety/Compliance: UL listed and CSA certified; RoHS, CE, and ISO compliant
Product Data Sheet
| ITEM NO | DIMENSIONS | ||||||
| φE | ΦD | Φd | W | B | L | H | |
| CL14-2H-6 | 6.4 | 8.8 | 5.8 | 13 | 28.5 | 117.5 | 45 |
| CL22-2H-8 | 8.4 | 11.3 | 7.7 | 16 | 28.5 | 119.2 | 45 |
| CL38-2H-10 | 10.5 | 12.4 | 9.8 | 18.3 | 31.7 | 120 | 45 |
| CL38-2H-12 | 13 | 12.4 | 9.8 | 18.3 | 31.7 | 120 | 45 |
| CL60-2H-10 | 10.5 | 14 | 11 | 20.5 | 40 | 130 | 45 |
| CL60-2H-12 | 13 | 14 | 11 | 20.5 | 40 | 130 | 45 |
| CL70-2H-10 | 10.5 | 15 | 12 | 21.4 | 40 | 130 | 45 |
| CL70-2H-12 | 13 | 15 | 12 | 21.4 | 40 | 130 | 45 |
| CL80-2H-12 | 13 | 16 | 13 | 23.2 | 40 | 130 | 45 |
| CL100-2H-12 | 13 | 18 | 14 | 26 | 42 | 132 | 45 |
| CL125-2H-12 | 13 | 20 | 16 | 29 | 42 | 135 | 45 |
| CL150-2H-12 | 13 | 22 | 17 | 31 | 50 | 150 | 45 |
| CL180-2H-12 | 13 | 23 | 18.2 | 33 | 50 | 150 | 45 |
| CL200-2H-12 | 13 | 26 | 20 | 37 | 52.5 | 150 | 45 |
| CL250-2H-12 | 13 | 28 | 22 | 40 | 50 | 150 | 45 |
| CL325-2H-12 | 13 | 32 | 25 | 46 | 68 | 180 | 45 |
| CL400-2H-12 | 13 | 37 | 30 | 54 | 60 | 180 | 45 |
| CL500-2H-12 | 13 | 40 | 31 | 57.5 | 60 | 180 | 45 |
| B-CL14-2H-6 | 6.4 | 8.3 | 5.8 | 13 | 28.5 | 117.5 | 45 |
| B-CL22-2H-8 | 8.4 | 10.7 | 7.7 | 16 | 28.5 | 119.2 | 45 |
| B-CL38-2H-10 | 10.5 | 11.9 | 9.8 | 17.5 | 31.7 | 120 | 45 |
| B-CL38-2H-12 | 13 | 11.9 | 9.8 | 17.5 | 31.7 | 120 | 45 |
| B-CL60-2H-10 | 10.5 | 13.5 | 11 | 19.5 | 40 | 130 | 45 |
| B-CL60-2H-12 | 13 | 13.5 | 11 | 19.5 | 40 | 130 | 45 |
| B-CL70-2H-10 | 10.5 | 14.5 | 12 | 21.4 | 40 | 130 | 45 |
| B-CL70-2H-12 | 13 | 14.5 | 12 | 21.4 | 40 | 130 | 45 |
| B-CL80-2H-12 | 13 | 15.5 | 13 | 23.2 | 40 | 130 | 45 |
| B-CL100-2H-12 | 13 | 17.3 | 14 | 26 | 42 | 132 | 45 |
| B-CL125-2H-12 | 13 | 19.3 | 16 | 28 | 42 | 135 | 45 |
| B-CL150-2H-12 | 13 | 21.1 | 17 | 31 | 50 | 150 | 45 |
| B-CL180-2H-12 | 13 | 22.1 | 18.2 | 33 | 50 | 150 | 45 |
| B-CL200-2H-12 | 13 | 24.9 | 20 | 36 | 50 | 150 | 45 |
| B-CL250-2H-12 | 13 | 26.9 | 22 | 39 | 50 | 150 | 45 |
| B-CL325-2H-12 | 13 | 30.7 | 25 | 45 | 68 | 180 | 45 |
| B-CL400-2H-12 | 13 | 35.7 | 30 | 54 | 60 | 180 | 45 |
| B-CL500-2H-12 | 13 | 38.4 | 31 | 56 | 60 | 180 | 45 |
