Soft aluminum tie wire (6063 grade). Dead-soft annealed, high malleability. Won't nick conductors. UV resistant.
Application
Soft aluminum tie wire (6063 grade or equivalent) for bundling and securing bare overhead conductors to pole top and crossarm insulators in overhead power distribution systems. Used to attach conductors to pin/post insulators, strap cables to crossarm brackets, and for general LV line tie-in applications. Annealed aluminum for high malleability and easy hand forming without tool marks. UV resistant. Also serves as overhead line repair binding.
Core Strengths
Line crews need fast, reliable conductor tying without damaging the parent conductor. Our aluminum tie wire is dead-soft annealed 6063 grade—easy hand wrapping with excellent malleability, won't nick or scratch conductor surfaces during installation. UV resistant. Consistent diameter. Wide spool packaging.
Standard
ASTM B609
Construction
☉〉 Material: Annealed aluminum
☉〉 Form: Single solid wire (various diameters)
☉〉 8AWG – 2AWG
Features
☉〉 Soft and ductile for easy hand or tool binding
☉〉 Corrosion-resistant for long-term outdoor use
☉〉 Lightweight and conductive
☉〉 Commonly used for tying conductors to insulators or overhead lines
Product Data Sheet
| Product Data Sheet-Tie WIRE | |||
| Size | Wire Dia. | Tensile Strength | Approx. Weight |
| AWG | mm | MPa | (lbs/1000ft) |
| 8 | 3.28 | 60～95 | 22.6 |
| 6 | 4.11 | 60～95 | 35.8 |
| 4 | 5.18 | 60～95 | 56.7 |
| 2 | 6.55 | 60～95 | 90.7 |
